Engineering manual - UniSAB III 1.10.8
001930 en 2021.06
159/346
History
4.1.2 Numbering of inputs/outputs
I/O
type
No.
Screw
compressors
Reciprocating
compressors
SABCube Chiller
Digital input
1
Compressor motor
feedback
Compressor motor
feedback
(Compressor motor
feedback)
-
2
Oil pump feedback
Intermediate oil re-
turn from sep. -
thermostat
- -
3
Oil pump 2/cooling
fan feedback
High pressure oil re-
turn from sep. -
thermostat
Water pump
feedback
-
4
Emergency stop Emergency stop Emergency stop -
5 Oil level/flow switch
Oil filter differential
switch
Oil level switch
Liquid level switch
6
External starting per-
mission
- normal stop
External starting per-
mission
- normal stop
External starting per-
mission
- normal stop
-
7
External starting per-
mission
- immediate stop
External starting per-
mission
- immediate stop
External starting per-
mission
- immediate stop
-
8
Regulator SP1/SP2 Regulator SP1/SP2 Regulator SP1/SP2 -
9
Motor current limiter
SP1/SP2
Motor current limiter
SP1/SP2
Motor current limiter
SP1/SP2
-
10
Start request feed-
back (PMS)
Start request feed-
back (PMS)
Start request feed-
back (PMS)
-
11
Capacity down
blocked
Capacity down
blocked
Capacity down
blocked
No flow in
condenser
12
-
Thermo pump level
low
-
No flow in
evaporator
13
-
Thermo pump level
high
-
Evaporator level
switch
14
Thermistors in motor
windings
Thermistors in motor
windings
Thermistors in motor
windings
-
Table 33: Numbering of digital inputs
