Set-up
Set-up/Configuration
No. Function Use
Choices
Communication
1 Compressor * 1/2 No. 1-14
2 Baud rate * 1/2 1200, 2400, 4800, 9600, 19200
3 Danbuss master enable
1/2
No, Yes
4
Profibus * 1/2
Yes, No
5
Profibus node no. * 1/2
1 to 254
6
Profibus baud rate 1/2 Auto adjust (9600-1.5 M)
7
GSD file no. * 1/2 08AA, 095D
8 Dig. input by com
1/2 Off, Modbus, Profbus
9 Evolution
1/2
No, Yes
Measuring
1
Pressure/temperature ** 1/2 Bar/°C/R, Psi/°F, kPa/°C
2
Pressure range ** 1/2 9/25/25/25, 25/59/25/25, 25/59/59/59
3 Low suction pressure
1/2
Yes, No
4
Capacity signal
2
Cap. pos, Freq.
5
SMC LL
1
No/Yes
6 Suction pressure gradient reset 1/2 0.0 to 20.0 *C [3.0 *C]
7 Yield rate up limitation
1/2 0.2 to 3.0 %/sec [2.0 %/sec]
8 Yield rate down limitation
1/2 0.2 to 3.0 %/sec [1.0 %/sec]
External (user 1) input
1 Function
1/2 Not used, Suction pressure setpoint, Process out
setpoint, Discharge pressure setpoint, Hot water
setpoint, Capacity setpoint, External input signal
2 4 mA
1/2 -999.9 to 999.9
3 20 mA
1/2
-999.9 to 999.9
Aux. output
1 Activate when
1/2 Not defined, Ready, At min. cap., At max. cap.,
Running, Ready ext., Ready/me only, Running at
max. cap.
2
Signal low 1/2
0 to 100
3
Signal high 1/2
0 to 100
Quick Setup
1
Rotatune * 1/2
No, Yes
2
Compressor type ** 1/2 Screw or reciprocating compressor
3 Refrigerant. ** 1/2 Not defined, R717, R22 etc.
4
Compressor * 1/2 1-14
5
Baud rate * 1/2
1200, 2400, 4800, 9600, 19200
6
GSD file no * 1/2
08AA, 095D
7
Profibus * 1/2
No, Yes
8 Profi Node no. * 1/2 1 to 254
9
Press/temp ** 1/2 Bar/°C/R, Psi/°F, kPa/°C
Factory reset
1
Factory reset ** 1/2
Yes, No
Table 44: Set-up/configuration
