Johnson Controls SABROE UniSAB III User Manual

Engineering manual - UniSAB III 1.10.8
342/346
001930 en 2021.06
Spare parts
Position transmitter for SAB (RWF) compressors
Description
SAB 193 SAB 233 SAB 283 SAB 355
Capacity
transmitters
Aluminium tube
for LS
534D1251H02 534D1251H02 534D1251H02 534D1251H02
Linear transmit-
ter (2) LS
534D1251H03 534D1251H03 534D1251H03 534D1251H03
Volume
transmitters
Indicator rod for
SS
534C1314H01 534C1314H01 534C1314H02 534C1314H03
Linear transmit-
ter (1) SS
534C1478H02 534C1478H02 534C1478H02 534C1478H02
Description
SAB 193 H SAB 233 H SAB 283 H SAB 355 H
Capacity
transmitters
Aluminium tube
for LS
534D1251H02 534D1251H02 534D1251H02 534D1251H02
Linear transmit-
ter (2) LS
SA96DX-I/Ex SA96DX-I/Ex SA96DX-I/Ex SA96DX-I/Ex
(1) Short stroke, without sensor pocket.
Short-stroke linear transmitter assembly, with sensor pocket: 534C1478H01.
(2) Long stroke, without sensor pocket.
Long-stroke linear transmitter assembly, with sensor pocket: 534D1251H01.
Position transmitter for new SAB (XJS, SJF) compressors
Description
SAB 120 SAB 151
Indicator rod for SS
534B0987H01 534B0872H01
Linear transmitter (3) SS 534C1552H02 534C1552H02
(3) Short stroke, without sensor pocket.
Short-stroke linear transmitter assembly, with sensor pocket: 534C1552H01.
