JUKI FX-1 - Replacing the STBL Home Position Sensor

FX-1/FX-1R Maintenance Manual
5-11. Replacing the STBL Home Position Sensor
(1 se sensor bracket.
(2)
c
L168E021000 BU SENSOR BRACKET
) Detach the nsor from the
d
L812E8210A0
SUPPORT TABLE NEAR
SENSOR ASM
e
SCREW SUPPLIED WITH
SENSOR
c
e
d
Table 5-11-1
Figure 5-11-1
Adjust the distance between the sensor and sensor dog to 1 mm.
Figure 5-11-2
5-15
Rev. 2.00
