FX-1/FX-1R Maintenance Manual
5-19. Layout of solenoid valves
The following figure shows the layout of solenoid valves.
A
TC L
STOPPER
CHK CYL
A
TC R
Figure 5-19-1
5-23
Rev. 2.00
