1— Self adhesive rubber pads

5. Aach the surface of the magnet mount sheet that has the Running Junos logo to the rubber pads

(see Figure 71 on page 130).

Figure 71: Aaching the Magnet Mount Sheet to an EX2300-C Switch

1— Magnet mount sheet

130
