Figure 14: Management port LEDs on a QFX5240 switch
1—
Status LED
2—
Link acvity LED
Table 8 on page 27 shows the management port LEDs on a QFX5240 switch.
Table 8: Management Port LEDs on a QFX5240 Switch
LED Color State Descripon
Link acvity Unlit O No link is established, there is a fault, or the link is down.
Green On steadily A link is established, but there is no link acvity.
Blinking or ickering A link is established, and there is link acvity.
Status Unlit O Either the port speed is 10 Mbps or the link is down.
Green On steadily The port speed is I Gbps.
Green On steadily The port speed is 100 Mbps.
27
