Juniper SRX300 Hardware Guide

A fully configured services gateway contains the chassis with installed components,
listed in Table 14 on page 38, and an accessory box, which contains the parts listed in
Table 15 on page 38.
NOTE: The parts shipped with your services gateway can vary depending on
the configuration you ordered.
Table 14: Parts List for a Fully Configured SRX300 Services Gateway
QuantityComponent
1SRX300 Services Gateway chassis with six Gigabit Ethernet LAN ports and two
1 G SFP ports
1CAT5E cable
1DB9-to-RJ45 adapter
1USB console cable with Type-A and Mini-B USB plugs
1How to Set Up Your SRX300 Services Gateway
1Power supply adapter and power cord
Table15: Accessory/UpgradeParts List for the SRX300 Services Gateway
QuantityPart
1Juniper Networks Product Warranty and RoHS Card
1End User License Agreement
1Safety Guide
Related
Documentation
• Unpacking the SRX300 Services Gateway on page 37
Copyright © 2016, Juniper Networks, Inc.38
SRX300 Services Gateway Hardware Guide

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
