CHAPTER 15
Providing Power to the SRX300 Services
Gateway
•
Connecting the SRX300 Services Gateway to the Power Supply on page 55
•
Powering On the SRX300 Services Gateway on page 56
•
Powering Off the SRX300 Services Gateway on page 56
Connecting the SRX300 Services Gateway to the Power Supply
To connect the device to the power supply:
CAUTION: Before connecting the device to the power supply, attach an ESD
strap to an ESD point and place the other end of the strap around your bare
wrist.
1. Plug the DC connector end of the power cable into the power connector on the back
of the device as shown in Figure 12 on page 55.
2. Plug the AC adapter end of the power cable into an AC power outlet.
Figure 12: Connecting the SRX300 Services Gateway to the Power Supply
Related
Documentation
Powering On the SRX300 Services Gateway on page 56•
• Powering Off the SRX300 Services Gateway on page 56
