Table 16: Grounding Cable Specifications for the Services Gateway
SpecificationGrounding Requirement
14 AWG single-strand wire cableGrounding cable
Up to 4 AAmperage of grounding cable
Ring-type, vinyl-insulated TV14-6R lug or
equivalent
Grounding lug
Related
Documentation
Required Tools and Parts for Grounding the SRX300 Services Gateway on page 49•
• Connecting the SRX300 Services Gateway Grounding Cable on page 50
Connecting the SRX300 Services Gateway Grounding Cable
You ground the services gateway by connecting a grounding cable to earth ground and
then attaching it to the chassis grounding point located on the back panel of the device
using a metric M5 x 0.8, 12-mm-long grounding screw.
You must provide the following items:
•
One metric M5 x 0.8, 12-mm-long grounding screw
•
Grounding cables
•
Cable lugs (for example, Panduit LCC6-10A-L)
CAUTION: Before you connect power to the services gateway, a licensed
electrician must attach a cable lug to the grounding and power cables that
you supply. A cable with an incorrectly attached lug can damage the services
gateway (for example, by causing a short circuit).
To ground the device:
1. Attach an electrostatic discharge (ESD) grounding strap to your bare wrist, and connect
the strap to the ESD point on the chassis. For more details, see “Preventing Electrostatic
Discharge Damage to the SRX300 Services Gateway” on page 95.
2. Ensure that all grounding surfaces are clean and brought to a bright finish before
grounding connections are made.
3. Connect the grounding cable to a proper earth ground.
4. Place the grounding cable lug over the grounding point (sized for metric M5 x 0.8,
12-mm-long grounding screws) on the rear of the chassis as shown in
Figure 11 on page 51.
Copyright © 2016, Juniper Networks, Inc.50
SRX300 Services Gateway Hardware Guide
