Juniper SRX300 Hardware Guide

Maintaining the SRX300 Services Gateway Power Supply
To maintain the power supply on the services gateway:
•
Make sure that the power and grounding cables are arranged so that they do not
obstruct access to other device components.
•
Routinely check the PWR LED on the front panel. If this LED is solid green, the power
supplies are functioning normally.
•
Periodically inspect the site to ensure that the grounding and power cables connected
to the services gateway are securely in place and that there is no moisture accumulating
near the services gateway.
CAUTION: We recommend using a surge protector for the power connection.
Related
Documentation
• Required Tools and Parts for Maintaining the SRX300 Services Gateway Hardware
Components on page 73
• Routine Maintenance Procedures for the SRX300 Services Gateway on page 73
Copyright © 2016, Juniper Networks, Inc.74
SRX300 Services Gateway Hardware Guide

Juniper SRX300 Specifications

General

USB 2.0 ports quantity	1
Connectivity technology	Wired
SFP module slots quantity	2
Ethernet LAN (RJ-45) ports	6
Internal memory	4000 MB
Flash memory	8000 MB
Storage media type	Flash
Power consumption (typical)	15.4 W
Noise level	0 dB
Heat dissipation	85 BTU/h
Concurrent connections	64000
Mean time between failures (MTBF)	389820 h
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Routing protocols	BGP, CLNS, IS-IS, OSPF, RIP-1, RIP-2
Number of users	50 user(s)
Quality of Service (QoS) support	Yes
Firewall throughput	1000 Mbit/s
Mobile VPN IPSec	250
IPS/IDS throughput	100 Mbit/s
Harmonized System (HS) code	85176990

Weight and Dimensions

Weight	1980 g
Dimensions (WxDxH)	320.8 x 34.7 x 191 mm
