KEB COMBIVERT F6 Series User Manual

33
DEVICE DATA OF THE 400 V DEVICES
3.2.3 Input and output currents/ overload
Device size 21 22 23 24
Rated input current @ U
N = 400V
1)
IIN / A 99 126 158 189
Rated input current @ U
N_UL = 480V
1)
IIN_UL / A 85 106 128 162
Table 12: Input currents of the 400 V devices
1)
The values resulting from rated operation with B6 rectier circuit and mains choke 4% Uk.
Device size 21 22 23 24
Rated output current
@ U
N = 400V
IN / A 90 115 150 180
Rated output current
@ U
N_UL = 480V
IN_UL / A 77 96 124 156
Rated output overload (60 s)
1)
I60s/% 150
Overload current
1)
IOL/% => „3.2.3.1 Overload characteristic (OL)“
Software current limit
1) 2)
Ilim/% 150
Overcurrent
1)
IOC/% 180
Table 13: Output currents of the 400 V devices
1)
The values refer in % to the rated output current IN.
2)
Limitation of the current setpoint in closed-loop operation. This setpint limit is not active in v/f operation.
Output voltages and frequencies
Output voltage at AC supply
1)
Uout / V 0…UN_ac
Output frequency
2)
fout / Hz 0…599
Output phase 3
Table 10: Output voltages and frequencies of the 400V devices
1)
The voltage to the motor is dependent on the actual input voltage and the control method
(„Example of the calculation of the possible motor voltage:“).
2)
The output frequency is to be limited in such a way that it does not exceed 1/10 of the switching
frequency. Devices with higher max. output frequency are subject to export restrictions and are
only available on request.
3.2.2.1 Example of the calculation of the possible motor voltage:
The motor voltage for dimensioning of the drive is depending on the used components.
The motor voltage reduces according to the following table:
Component Reduction / % Example
Mains choke U
k 4
Open-loop drive converter with mains- and motor choke
at non-rigid supply system:
400 V mains voltage (100%) - 36 V reduced voltage (11 %)
= 356 V motor voltage
Drive converter open-loop 4
Drive converter closed-loop 8
Motor choke U
k 1
Non-rigid supply system 2
Table 11: Example of the calculation of the possible motor voltage:
