KEB COMBIVERT F6 Series

52
DIMENSIONS AND WEIGHTS
3.4.5 Push-through version uid cooler (oil) IP20, IP54-ready
18041
60
26
81,5
G 1/2
520
83,5 405 31,5
285
520
für/for M6
24,5183
245
± 1
481
± 1
R5...R10
90
101
90 90
101101101101
Housing 6
Weight 21 kg
Dimensions All dimensions in mm
Figure 12: Dimensions push-through version uid cooler (oil) IP20, IP54-ready
