DIMENSIONS AND WEIGHTS
3.4.3 Push-through version air cooler IP20, IP54-ready
285
(270,7)
90,8
179,9
für M6 (16x)
for M6 (16x)
Dichtung
gasket
77,5
183
24,5
520
499,5
475
24,5
für M6 (16x)
for M6 (16x)
0
101
202
303
404
505
0
90
180
270
0
12
Ausschnitt
cut-out
493
(481)
(245)
0
12,5
257,5
R5...R10
Housing 6
Weight 20.6 kg
Dimensions All dimensions in mm
Figure 10: Dimensions push-through version air cooler IP20, IP54-ready
