DIMENSIONS AND WEIGHTS
3.4.6 Control cabinet installation
3.4.6.1 Mounting instructions
For mounting the drive controllers, the following mounting materials were tested with the
corresponding quality by KEB.
Required material Tightening torque
Hexagon-head screw ISO 4017 - M8 - 8.8
22 Nm
194 lb inch
Flat washer ISO 7090 - 8 - 200 HV ―
Table 28: Mounting instructions for built-in version
Required material Tightening torque
Hexagon-head screw ISO 4017 - M6 - 8.8
9 Nm
80 lb inch
Flat washer ISO 7090 - 6 - 200 HV ―
Table 29: Mounting instructions for push-through version
NOTICE
Use of other mounting material
► The alternatively selected mounting material must comply with the
above-mentioned material characteristics (quality) and tightening
torques !
The use of other mounting materials is beyond KEB's control and is
therefore the sole responsibility of the customer.
