4.3.4 Side-mounted braking resistors
Technical data and design about intrinsically safe braking
resistors => https://www.keb.de/leadmin/media/Manuals/dr/ma_dr_
safe-braking-resistors-20106652_en.pdf
Technical data and design about non-intrinsically safe
braking resistors => https://www.keb.de/leadmin/media/Manuals/
dr/ma_dr_braking-resistors-20116737_en.pdf
74
ACCESSORIES
4.3 Accessories
4.3.1 Filters and chokes
Voltage class Drive controller size HF lter
Mains choke 50 Hz / 4 % Uk
400 V
21 22E6T60-3000 21Z1B04-1000
22 22E6T60-3000 22Z1B04-1000
23 24E6T60-3000 23Z1B04-1000
24 24E6T60-3000 24Z1B04-1000
Table 35: Filters and chokes
Thespeciedltersandchokesaredesignedforratedoperation.
4.3.2 Seal for IP54-ready devices
Name
Material number
Flat seal IP54 60F6T45-0002
Table 36: Seal for IP54-ready devices
4.3.3 Connections to the coolant
Name
Material number
Functional nut for 10 mm tube 0000651-FM10
Table 37: Connections to the coolant
