65
CONNECTION OF THE POWER UNIT
4.2.5 Connection of the motor
4.2.5.1 Wiring of the motor
U
V
W
U
V
W
5
6
X1C
X1A
9
10
Control
P A/K
Legend
①
KEB COMBIVERT
②
Apply motor cable, shielding on both sides over a large surface on the bare metallic frame or mounting
plate (remove paint if necessary)
③
Three-phase motor
④
Temperature monitoring (optional) => Instructions for use „Control circuit“
Figure 24: Wiring of the motor
