KEB COMBIVERT F6 Series User Manual

51
DIMENSIONS AND WEIGHTS
3.4.4 Push-through version uid cooler (water) IP20, IP54-ready
285
(211,9)
179,9
für M6 (16x)
for M6 (16x)
32
Dichtung
gasket
77,5 183
24,5
24,5
520
(525,5)
410
91
für M6 (16x)
for M6 (16x)
0
101
202
303
404
505
0
90
180
270
0
12
Ausschnitt
cut-out
493
(481)
(245)
0
12,5
257,5
R5...R10
Housing 6
Weight
17.3 kg without sub-mounted braking resistors
19.2 kg without sub-mounted braking resistors
Dimensions All dimensions in mm
Figure 11: Dimensions push-through version uid cooler (water) IP20, IP54-ready
