48
DIMENSIONS AND WEIGHTS
3.4 Dimensions and weights
3.4.1 Built-in version air cooler
200
(24,4)
271,9
249
für M8 (4x)
for M8 (4x)
9
(12,5)
13
16
(525)
525
500
12,5
Housing 6
Weight 21.5 kg
Dimensions All dimensions in mm
Figure 8: Dimensions built-in version air cooler
