Setpoint for pressure, volumetric flow rate, cylinder speed, cylinder position. The unit
(HYD_UNIT) depends on the control mode and corresponds to bar for pressure
control, l/min for volumetric flow rate control and rpm for pump speed control. For
cylinder position and speed control, the unit corresponds to the UserUnit selected in
the scaling (chapter 8.2). This also applies for derivative 1 and 2 or speed and
acceleration.
ID Index Name Unit Description
2857  HYD_Ref  Hydraulic:Setpointforvolumetricflow
rate/pressure/speed/position
2857 0..15 HYD_Ref HYD_Unit Hydraulic:Setpointforvolumetricflow
rate/pressure/speed/position
Table 7.68: “Hydraulic - Reference value” parameters
1st reference value derivative
Rise time/speed of the setpoint
ID Index Name Unit Description
2858  HYD_dRef  Hydraulic:1stsetpointderivative
2858 0..15 HYD_dRef HYD_UNIT/s Hydraulic:1stsetpointderivative
Table 7.69: “Hydraulic - 1st setpoint derivative” parameters
2nd setpoint derivative
Setpoint acceleration (this parameter is not active for pressure and volumetric flow
rate)
ID Index Name Unit Description
2859  HYD_d2Ref  Hydraulic:2ndsetpointderivative
2859 0..15 HYD_d2Ref HYD_UNIT/s/s Hydraulic:2ndsetpointderivative
Table 7.70: “Hydraulic - 2nd setpoint derivative” parameters
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
196
7 Control
Hydraulic control parameters table
For the control of the valve position, switching of the position controller settings and
of the pump data set as well as for enabling the active decompression, the
respective bits can be enabled in this parameter for every motion block. The active
decompression prevents that a motion block is started as long as pressure is still
applied. If the bit is active, the pressure is reduced via a defined ramp (P 2850.11
decmpRate) below a specified pressure level (P 2850.10 decmpLvl) before the
respective motion block is started.
Bit Designation Meaning
0 ZylArea(A1/A2) SwitchoverofthecylinderArea
1 Reserved 
2 POS Extendthehydraulicvalvecylinder
3 neg Retractthehydraulicvalvecylinder
4 Opt1 Valveoption1
5 Opt2 Valveoption2
6 PosCon2 Selectionforsecondposition-controllersettingP 2871 HYD_PosConAdv2
7 Reserved 
8 PumpSet2 SelectionforsecondpumpdatasetP 2873 HYD_Pump2
9 Reserved 
10 AktivDecomp Activedecompressionfortherespectivemotionblock
11 Reserved 
12 PressCon2 Selectionforsecondpressure-controllersettingP 2874 HYD_PressCon2
Table 7.71: Control parameters table
ID Index Name Unit Description
2863  HYD_TabCtrl  
2863 0..15 HYD_TabCtrl  HydraulicTablecontrolword
Table 7.72: Parameter “Hydraulic table control word”
Scaling of the hydraulic limits
