ID Index Name Unit Description
429 0 ISA00_gain GainscalingforinputISA00
429 1 ISA01_gain GainscalingforinputISA01
429 2 ISA00_limMin MinimumvalueforinputISA00
429 3 ISA01_limMin MinimumvalueforinputISA01
429 4 ISA00_limMax MaximumvalueforinputISA00
429 5 ISA01_limMax MaximumvalueforinputISA01
665 0 DV_CAL_IsaType Analogueinputs:Switchbetweencurrent/voltage
input
Table 9.11: “Analogue inputs” parameters (continue)
9.4.2Functionselectors
Before using the analogue inputs, they are normally associated with a special
device functionality for analogue inputs. The corresponding function selectors also
make it possible to select a special digital functionality instead.
ID Index Name / Setting Unit Description
109-110 0 MPRO_INPUT_FS_
ISA0x
“Analogueinputs”“functionselectors”
PRC_REF(-14) Processcontrollerreferencevalue
PRC_ACT(-13) Processcontrolleractualvalue
ENC_ANA(-12) Analogueencoder(onchannel4)
TWIN_SCALE(-11) TWINpositionscaling
HYD_Q_ACT(-10) Hydraulicactualflow(softwarespecific)
HYD_P_ACT2(-9) Hydraulicactualpressureon2ndsensor
(softwarespecific)
HYD_Q_REF(-8) Hydraulicreferenceflow(softwarespecific)
HYD_P_ACT(-7) Hydraulicactualpressure(softwarespecific)
HYD_P_REF(-6) Hydraulicreferencepressure(softwarespecific)
VFC_REF_SCALE(-5) VFCreferencescaling0-100%(software
specific)
TLIM(-4) Analoguetorquelimit0-100%
OVR(-3) Speedoverride0-100%atpositioning
Table 9.12: “Analogue inputs” function selectors
ID No.: 0842.26B.5-01Date: 09.2020
ServoOne- Device Help
317
9 Inputs/Outputs settings
ID Index Name / Setting Unit Description
REFV(-2) Analoguereference
(-1) Notdefined
Off(0) Nofunction
START(1) Startmotorcontrol
INV(2) Inversereferencevalue
STOP(3) Executequickstop
HALT(4) Disablefeed
LCW(5) Limitswitchpositivedirection
LCCW(6) Limitswitchnegativedirection
INCH_P(7) JogPositive
INCH_N(8) JogNegative
HOMST(9) Starthoming
HOMSW(10) Referenceswitch
E_EXT(11) Externalerror
WARN(12) Externalwarning
RSERR(13) Resetalarm
MAN(14) Switchcontrollocationselector
(15) Notdefined
PLC(16) UsedinPLC
PLC_IR(17) PLCinterrupt
MP_UP(18) MotorpotentiometerNegative
MP_DOWN(19) MotorpotentiometerPositive
(20)-(20) Notdefined
TBEN(21) Enableselectedtableindex
TBTEA(22) Writeactualpositionintoselectedtableindex
TAB0(23) Binarytableindex2^0
TAB1(24) Binarytableindex2^1
TAB2(25) Binarytableindex2^2
TAB3(26) Binarytableindex2^3
EGEAR(27) Start/stopEgear
REFANAEN(28) Enableanaloguereference
(29) Notdefined
(30) Notdefined
