- 113 -
Installing the oil machine
Shown as the f
ollowing figure
10.3.2 Installation
Conduct in a sequence contrary to the
―
removing
‖
.
10.3.3 Check
Check whether
the worm gear sur
face has been damaged
.
Check whether t
he keyway
has been damaged.
Measure the plun
ger outside diam
eter
.
A
vailable lim
it: 2.61mm.
Carbur
etor
外转子
内转子
机油泵盖
螺钉
定位销
机油泵体
Machine
oil
pump
cover
Machine oil pump
齿轮
Gear
Machine
oil
pump
body
Plunger
outsi
de
diameter
Plunger spring
Plunger
113
