KEEWAY F-ACT EVO User Manual

- 114 -
1 screw 2 float chamber 3 needle valve component 4 float 5 float pin 6 main hole 7 idle
nozzle 8 main foam tube
9 idle adjusting screw
Note: Since the gasoline is
very dangerous, smoke and
fire is strictly prohibited in
the operation site.
After carburetor being
removed, use rag to block
the inlet pipe in order to
prevent foreign body in.
曲轴箱
化油器
