15. Speed Reducer
Preparation Data----------------- 15.1
Fault Diagnosis ----------------- 15.2
Gearbox ------------------- 15.3
Installation --------------------- 15.4
15.1 Preparation Data
Effect: Transfer the torque and determine the final output torque and rotational speed.
15.2 Fault Diagnosis
Vehicle can not move in spite of the starting engine;
Drive gear was damaged;
Drive gear was burned;
Gear oil was leaked;
Gear oil was too much;
Grease seal was damaged;
15.3 Gear Box
15.3.1 Disassembly
Remove the oil drain nut and release the gear oil out from gear box.
Loosen the bolts and remove the gear box cover.
