Keysight Technologies E3646A User Manual

3 Remote Interface Reference
Simplified Programming Overview
82 E364xA User’s and Service Guide
Power supply programming ranges
The SOURce subsystem requires parameters for programming
values. The available programming value for a parameter
varies according to the desired output range of the power
supply.
Table 3- 2 lists the programming values available and
the MINimum, MAXimum, DEFault, and reset values of your
power supply.
Refer to Table 3- 2 to identify the programming values when
programming the power supply.
Table 3 - 2 Keysight E364xA programming ranges
E3646A E3647A E3648A E3649A
0 to 8 V
/3 A
range
0 to 20 V
/1.5 A
range
0 to 35 V
/0.8 A
range
0 to 60 V
/0.5 A
range
0 to 8 V
/5 A
range
0 to 20 V
/2.5 A
range
0 to 35 V
/1.4 A
range
0 to 60 V
/0.8 A
range
Voltage Programming range 0 V to
8.24 V
0 V to
20.60 V
0 V to
36.05 V
0 V to
61.8 V
0 V to
8.24 V
0 V to
20.60 V
0 V to
36.05 V
0 V to
61.8 V
MAX value 8.24 V 20.60 V 36.05 V 61.8 V 8.24 V 20.60 V 36.05 V 61.8 V
MIN value 0 V0 V0 V0 V
DEFault value 0 V0 V0 V0 V
*RST value 0 V0 V0 V0 V
Current Programming range 0 A to
3.09 A
0 A to
1.545 A
0 A to
0.824 A
0 A to
0.515 A
0 A to
5.15 A
0 A to
2.575 A
0 A to
1.442 A
0 A to
0.824 A
MAX value 3.09 A 1.545 A 0.824 A 0.515 A 5.15 A 2.575 A 1.442 A 0.824 A
MIN value 0 A0 A0 A0 A
DEFault value 3 A 1.5 A 0.8 A 0.5 A 5 A 2.5 A 1.4 A 0.8 A
*RST value 3.00 A0.8 A5.00 A1.4 A
