Recommended Test Equipment
E364xA User’s and Service Guide 189
Recommended Test Equipment
Table 8- 4 describes the test equipment recommended for the
performance verification and adjustment procedures. If the
exact instrument is not available, use the accuracy
requirements shown to select substitute calibration
standards. If you use equipment other than the
recommended equipment shown in
Table 8- 4, you must
recalculate the measurement uncertainties for the actual
equipment used.
Table 8 - 4 Recommended test equipment
Equipment Requirements Recommended model Test function
GPIB controller Full GPIB or RS-232 capabilities Keysight 82357B interface
card or equivalent
Programming and readback
accuracy
Oscilloscope 100 MHz with 20 MHz bandwidth Keysight DSO5034A or
equivalent
Display transient response
and ripple and noise
waveform
Rms voltmeter 20 Hz to 20 MHz Keysight 54602B
oscilloscope or R&S URE3
rms voltmeter
Measure rms ripple and noise
Cable (BNC-to-BNC) 50 Ω, 9 inch (23 cm) Keysight 10502A or 10503A if
the 10502A is not available
Measure rms ripple and noise
(CV PARD, CC PARD)
BNC (female) bulkhead
receptacle
• Isolated ground
• Nominal impedance: 50 Ω
Pomona Model 5148 Measure rms ripple and noise
(CV PARD, CC PARD)
Split ferrites For use with round cable Steward Co. 28A2029-0A0 Noise coupling reduction
Digital voltmeter • Resolution: 0.1 mV
• Accuracy: 0.01%
Keysight 34401A Measure DC voltages
Electronic load • Voltage range: 240 Vdc
• Current range: 10 Adc
• Open and short switches
• Transient on/off
Keysight 6060B or equivalent Measure load and line
regulations and transient
response time
