Performance Test Record
Table 8 - 6 CV performance test record
Test description Models Output Actual result Specifications
Upper limit Lower limit
CV programming accuracy
at 0 V (DVM reading)
all Output1 +0.0100 V –0.0100 V
Output2 +0.0250 V +0.0250 V
CV readback accuracy
at 0 V
all Output1 DVM + 0.0050 V DVM – 0.0050 V
Output2 DVM + 0.0250 V DVM – 0.0250 V
CV programming accuracy
at full-scale (DVM reading)
E3646A/E3648A Output1 20.0200 V 19.9800 V
Output2 20.0450 V 19.9550 V
E3647A/E3649A Output1 60.0400 V 59.9600 V
Output2 60.0850 V 59.9150 V
CV readback accuracy
at full-scale
E3646A/E3648A Output1 DVM + 0.0150 V DVM – 0.0150 V
Output2 DVM + 0.0450 V DVM – 0.0450 V
E3647A/E3649A Output1 DVM + 0.0350 V DVM – 0.0350 V
Output2 DVM + 0.0850 V DVM – 0.0850 V
CV load effect (load
regulation)
E3646A/E3648A all Maximum change: <5 mV
E3647A/E3649A all Maximum change: <9 mV
CV source effect (line
regulation)
E3646A/E3648A all Maximum change: <5 mV
E3647A/E3649A all Maximum change: <9 mV
CV PARD (normal mode) E3646A/E3648A all <5 mVpp / 0.5 mVrms
E3647A/E3649A all <8 mVpp / 1 mVrms
Load transient response time all all <50 μs
