2 Operation and Features
Storing and Recalling Operating States
44 E364xA User’s and Service Guide
4 Select the parity and number of stop bits.
Select one of the following: None (8 data bits, factory
setting), Odd (7 data bits), or Even (7 data bits). When
you set the parity, you are also indirectly setting the
number of the data bits.
NONE 8 BITS
5 Save the change and exit the menu.
SAVED
Storing and Recalling Operating States
You can store up to five different operating states in
non- volatile storage locations. When shipped from the
factory, storage locations 1 through 5 are empty. You can
name a location from the front panel or over the remote
interface but you can only recall a named state from the
front panel.
The following steps show you how to store and recall an
operating state.
To cancel the store/recall operation, select the EXIT menu by
turning the knob and then pressing
or letting the
display time- out.
Front panel operation
Storing the operating state
1 Set up the power supply for the desired operating state.
The storage feature “remembers” the output voltage range
selection, the limit value settings of voltage and current,
output on/off state, OVP on/off state, and OVP trip levels.
To Next Page
