Keysight Technologies E3646A - Product at a Glance; Front Panel; Figure 1-3 Front Panel; Table 1-4 Front Panel Overview

Getting Started 1
Product at a Glance
E364xA User’s and Service Guide 17
Product at a Glance
Front panel
Figure 1-3 Front panel
Table 1 - 4 Front panel overview
No Item Description
1 Output 1 selection key Select the output 1 voltage and current to be controlled and
monitored on the display.
2 Output 2 selection key Select the output 2 voltage and current to be controlled and
monitored on the display.
