2 Operation and Features
Configuring the Remote Interface
42 E364xA User’s and Service Guide
Viewing the calibration string
1 Enter the View menu and select CAL STRING.
CAL STRING
2 Scroll through the text of the message.
FACTORY CAL 26/11/12
NO STRING is displayed if no calibration message is stored.
Press
to increase the scrolling speed. The Cal String
cannot be changed from the front panel. Refer to
“Calibration message” on page 66 for more information.
Configuring the Remote Interface
This power supply is shipped with both a GPIB (IEEE- 488)
interface and an RS- 232 interface. The GPIB interface is
selected when the power supply is shipped from the factory.
Only one interface can be enabled at a time. To exit the I/O
configuration mode without any changes, press
until
the NO CHANGE message is displayed.
• You can set the GPIB address, parity, and baud rate from
the front panel only.
• The current selection is highlighted for emphasis. All
other choices are dimmed.
• The interface selection is stored in the non- volatile
memory, and does not change when power has been
turned off or after a power- on reset (*RST command).
