Operation and Features 2
Configuring the Remote Interface
E364xA User’s and Service Guide 43
GPIB configuration
1 Turn on the remote configuration mode.
GPIB / 488
If RS-232 appears, select GPIB / 488 by turning the knob.
2 Select the GPIB address.
ADDR 05
You can set the power supply’s address to any value
between 0 and 30. The factory setting is address 5.
3 Save the change and exit the menu.
SAVED
RS-232 configuration
1 Turn on the remote configuration mode.
GPIB / 488
Notice that if you changed the remote interface selection
to RS- 232 before, the RS-232 message is displayed.
2 Choose the RS- 232 interface.
RS-232
You can choose the RS- 232 interface by turning the knob.
3 Select the baud rate.
Select one of the following: 300, 600, 1200, 2400, 4800, or
9600 (factory setting) baud.
9600 BAUD
Your computer's GPIB interface card has its own address. Be sure to avoid
using the computer's address for any instrument on the interface bus.
Keysight GPIB interface cards generally use address 21.
