Operation and Features 2
Track Mode Operation
E364xA User’s and Service Guide 39
Front panel operation
1 Set either the output1 or the output2 supply to the desired
voltage.
2 Enable the track mode.
HOLD_KEY
Hold down until the Tr ack annunciator turns on. For
example, when the track mode is first enabled with the
output1 selected, the output2 supply will be set to the
same voltage level as the output1 supply. Once enabled,
any change of the voltage level in either the output1 or
the output2 supply will be reflected in other supply. The
current limit is independently set for each of the output1
or the output2 supply and is not affected by the track
mode.
3 Exit the track mode.
The Track annunciator turns off.
Remote interface operation
The tracking accuracy is dependent upon the voltage programming
accuracy of each output. Refer to “Electrical Specifications” on page 172
for more information.
OUTPut:TRACk[:STATe]
{OFF|ON}
Disable/enable the
track mode.
OUTPut:TRACk[:STATe]? Queries the track
mode status.
