Getting Started 1
Introduction
E364xA User’s and Service Guide 5
Figure 1-1 Rear output terminals
1 Float voltage ±60 Vdc Max to (shorting conductors
without insulation).
2 Float voltage ±240 Vdc Max to (insulated shorting
conductors).
Floating the power supply output at more than ±60 Vdc from the
chassis presents an electric shock hazard to the user.
Do not float the outputs at more than ±60 Vdc when uninsulated
sense wires are used to connect the (+) output to the (+) sense and
the (–) output to the (–) sense terminals on the back of the unit.
