Operation and Features 2
System-Related Operations
E364xA User’s and Service Guide 53
Front panel operation
STORE STATE, NAME STATE, EXIT
To reset the power supply to the power- on reset state
without using the *RST command or turning power off/on,
select RESET from the following.
5 states, RESET, EXIT
Remote interface operation
Use the following commands to store and recall power
supply states.
*SAV {1|2|3|4|5}
*RCL {1|2|3|4|5}
To assign a name to a stored state to be recalled from the
front panel, send the following command. From the remote
interface, you can only recall a stored state using a number
(1 through 5).
MEM:STAT:NAME 1, ‘P15V_TEST’
Self-test
A power- on self- test occurs automatically when you turn on
the power supply. This test assures you that the power
supply is operational. This test does not perform the
extensive set of tests that are included as part of the
complete self- test described below. If the power- on self- test
fails, the ERROR annunciator turns on.
A complete self- test performs a series of tests and takes
approximately 2 seconds to execute. If all tests pass, you can
have a high confidence that the power supply is operational.
