Operation and Features 2
Storing and Recalling Operating States
E364xA User’s and Service Guide 45
2 Turn on the storage mode.
STORE STATE
From the front panel, you can assign names (up to nine
characters) to each of the five stored states. Turn the
knob until NAME STATE appears and press
to select
the locations. Then press to name the locations.
NAME STATE
1:P15V_TEST
3 Select the storage location.
Turn the knob to the right to specify the memory
location 2.
2: STATE2
4 Save the operating state.
DONE
Recalling a stored state
1 Turn on the recall mode.
Memory location 1 will be displayed in the recall mode.
1: P15V_TEST
2 Select the stored operating state.
2: STATE2
RESET
You can select the above RESET mode to reset the power
supply to the power- on state without turning power
off/on or without using the *RST command over the
remote interface. Refer to
“*RST” on page 98 for more
details on the *RST command.
3 Recall the stored operating state.
DONE
Before proceeding with the steps listed below, ensure that the outputs are
disabled throughout the recall procedure (the CV or CC annunciator turns
off and the OFF annunciator turns on).
