2 Operation and Features
Programming the Overvoltage Protection
48 E364xA User’s and Service Guide
• By adjusting the output voltage level
i Lower the output voltage level below the OVP trip point.
The OVP1 or OVP2, and Limit annunciators are flashing
after
is pressed.
ii Check that you lowered the voltage level below the OVP
trip point.
The OVP trip point is displayed. Do not adjust the trip
point at this step.
iii Select the OVP CLEAR mode by turning the knob.
OVP ON
OVP CLEAR
iv Clear the overvoltage condition and exit this menu.
DONE
The annunciator for the OVP operation will not flash
any more. The output will return to the meter mode.
• By adjusting the OVP trip level
i Raise the OVP trip level higher than the level tripped.
ii Select the OVP CLEAR mode by turning the knob.
OVP ON
OVP CLEAR
iii Clear the overvoltage condition and exit this menu.
DONE
The annunciator for the OVP operation will not flash
any more. The output will return to the meter mode.
