123
Keysight InfiniiVision 3000 X-Series Oscilloscopes
User's Guide
7 Serial Decode
Serial Decode Options / 123
Lister / 124
Searching Lister Data / 126
Triggering on
Serial Data
In some cases, such as when triggering on a slow serial signal (for example, I2C,
SPI, CAN, LIN, etc.) it may be necessary to switch from the Auto trigger mode to
the Normal trigger mode to prevent the oscilloscope from Auto-triggering and
stabilize the display. You can select the trigger mode by pressing the
[Mode/Coupling] key, then the Mode softkey.
Also, the threshold voltage level must be set appropriately for each source
channel. The threshold level for each serial signal can be set in the Signals Menu.
Press the [Serial] key, then the Signals softkey.
Serial Decode Options
Keysight's hardware-accelerated serial decode options can be installed when the
oscilloscope is manufactured, or added later. The following serial decode licenses
are available:
Licensed Serial Decode See:
CAN (Controller Area Network) and LIN (Local
Interconnect Network) serial buses.
• "CAN Serial Decode" on page 349.
• "LIN Serial Decode" on page 356.
FlexRay serial buses. • "FlexRay Serial Decode" on page 365.
