371

Keysight InfiniiVision 3000 X-Series Oscilloscopes

User's Guide

25 I2C/SPI Triggering and

Serial Decode

Setup for I2C Signals / 371

I2C Triggering / 372

I2C Serial Decode / 376

Setup for SPI Signals / 379

SPI Triggering / 383

SPI Serial Decode / 385

The I2C/SPI triggering and serial decode option is license-enabled.

Setup for I2C Signals

C (Inter-IC bus) signals setup consists of connecting the oscilloscope to the

serial data (SDA) line and the serial clock (SCL) line and then specifying the input

signal threshold voltage levels.

To set up the oscilloscope to capture I

C signals, use the Signals softkey which

appears in the Serial Decode Menu:

1 Press [Label] to turn on labels.

2 Press [Serial].

NOTE

Only one SPI serial bus can be decoded at a time.
