Waveform Generator 17
Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 259
Sine Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude/High-Level, and Offset/Low-Level
softkeys to set the sine signal parameters.
100 mHz to
20 MHz
20 mVpp to
5Vpp
±2.50 V
Square Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude/High-Level, Offset/Low-Level, and
Duty Cycle softkeys to set the square wave signal
parameters.
The duty cycle can be adjusted from 20% to 80%.
100 mHz to
10 MHz
20 mVpp to
5Vpp
±2.50 V
Ramp Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude/High-Level, Offset/Low-Level, and
Symmetry softkeys to set the ramp signal
parameters.
Symmetry represents the amount of time per cycle
that the ramp waveform is rising and can be
adjusted from 0% to 100%.
100 mHz to
200 kHz
20 mVpp to
5Vpp
±2.50 V
Pulse Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude/High-Level, Offset/Low-Level, and
Width/Width Fine softkeys to set the pulse signal
parameters.
The pulse width can be adjusted from 20 ns to the
period minus 20 ns.
100 mHz to
10 MHz.
20 mVpp to
5Vpp
±2.50 V
DC Use the Offset softkey to set the DC level. n/a n/a ±2.50 V
Noise Use the Amplitude/High-Level and
Offset/Low-Level to set the noise signal parameters.
n/a 20 mVpp to
5Vpp
±2.50 V
Sine Cardinal Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude, and Offset softkeys to set the sinc
signal parameters.
100 mHz to
1MHz
20 mVpp to
5Vpp
±1.25 V
Exponential
Rise
Use the Frequency/Frequency Fine/Period/Period
Fine, Amplitude/High-Level, and Offset/Low-Level
softkeys to set the exponential rise signal
parameters.
100 mHz to
5MHz
20 mVpp to
5Vpp
±2.50 V
Waveform
Type
Characteristics Frequency
Range
Max.
Amplitude
(High-Z)
1
Offset
(High-Z)
1
