Acquisition Control 12
Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 197
See Also • "Navigating Segments" on page 197
• "Measurements, Statistics, and Infinite Persistence with Segmented
Memory" on page 197
• "Segmented Memory Re-Arm Time" on page 198
• "Saving Data from Segmented Memory" on page 198
Navigating Segments
1 Press the Current Seg softkey and turn the Entry knob to display the desired
segment along with a time tag indicating the time from the first trigger event.
You can also navigate segments using the [Navigate] key and controls. See "To
navigate segments" on page 61.
Measurements, Statistics, and Infinite Persistence with Segmented
Memory
To perform measurements and view statistical information, press [Meas] and set up
your desired measurements (see Chapter 14, “Measurements,” starting on page
211). Then, press Analyze Segments. Statistical data will be accumulated for the
measurements you have chosen.
Progress indicator
Sample rate
