272 Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide

17 Waveform Generator

To restore waveform generator defaults

1 If the Waveform Generator Menu is not currently displayed on the

oscilloscope's softkeys, press the [Wave Gen] key.

2 In the Waveform Generator Menu, press the Settings softkey.

3 In the Waveform Generator Settings Menu, press the Default Wave Gen softkey.

The waveform generator factory default settings (1 kHz sine wave, 500 mVpp,

0 V offset, High-Z output load) are restored.
