218 Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide

14 Measurements

You can also configure the [Quick Action] key to display the Snapshot All popup.

See "Configuring the [Quick Action] Key" on page 307.

Voltage Measurements

The following figure shows the voltage measurement points.

Measurement units for each input channel can be set to Volts or Amps using the

channel Probe Units softkey. See "To specify the channel units" on page 69.

The units of math waveforms are described in "Units for Math Waveforms" on

page 75.

• "Peak-Peak" on page 219

• "Maximum" on page 219

Amplitude

Maximum

Minimum

Base

Top

Peak-Peak
