Measurements 14

Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 233

This measurement is available for analog channels.

Negative Pulse Count

The Negative Pulse Count measurement is a pulse count for the selected waveform

source.

This measurement is available for analog channels.

Rising Edge Count

The Rising Edge Count measurement is an edge count for the selected waveform

source.

This measurement is available for analog channels.

Falling Edges Count

The Falling Edges Count measurement is an edge count for the selected waveform

source.

This measurement is available for analog channels.

Positive pulse count

Negative pulse count
