Reference 22
Keysight InfiniiVision 3000 X-Series Oscilloscopes User's Guide 329
Licensed Options Available
The following licensed options can be easily installed without returning the
oscilloscope to a Service Center. See data sheets for details.
Table 4 Licensed Options Available
License Description After purchase model number, notes
D3000AERA Aerospace Software for 3000 X-Series
Replaces licenses AERO, VID, MASK, and ADVMATH.
Order D3000AERA (replaces DSOX3AERO,
DSOX3VID, DSOX3MASK, and
DSOX3ADVMATH).
D3000AUTA Automotive Software for 3000 X-Series
Replaces licenses AUTO, FLEX, MASK, and ADVMATH.
Order D3000AUTA (replaces DSOX3AUTO,
DSOX3FLEX, DSOX3MASK, and
DSOX3ADVMATH).
D3000GENA General Purpose Software for 3000 X-Series
Replaces licenses EMBD, COMP, MASK, AUDIO, VID, and
ADVMATH.
Order D3000GENA (replaces DSOX3EMBD,
DSOX3COMP, DSOX3MASK, DSOX3AUDIO,
DSOX3VID, and DSOX3ADVMATH).
D3000PWRA Aerospace Software for 3000 X-Series
Replaces licenses PWR, MASK, and ADVMATH.
Order D3000PWRA (replaces DSOX3PWR,
DSOX3MASK, and DSOX3ADVMATH).
ADVMATH Advanced Math Measurements. Order D3000GENA, D3000AUTA,
D3000AERA, or D3000PWRA (which include
and replace DSOX3ADVMATH).
AERO MIL-STD-1553 and ARINC 429 Serial Triggering and
Analysis.
Order D3000AERA (replaces DSOX3AERO
and others).
AUDIO Audio Serial Triggering and Analysis (I2S). Order D3000GENA (replaces DSOX3AUDIO
and others).
AUTO Automotive Serial Triggering and Analysis (CAN,LIN). Order D3000AUTA (replaces DSOX3AUTO
and others).
COMP Computer Serial Triggering and Analysis
(RS232/422/485/UART).
Provides trigger and decode capability for many UART
(Universal Asynchronous Receiver/Transmitter) protocols
including RS232 (Recommended Standard 232).
Order D3000GENA (replaces DSOX3COMP
and others).
DVM Digital Voltmeter
Provides provides 3-digit voltage and 5-digit frequency
measurements using any analog channel.
Now standard.
