14 Measurements
Power App
Measurements
Note that additional Power App measurements are available when the power
measurement and analysis license is installed and the Power Application is
enabled. For more information, see the Power Measurement Application User's
Guide at www.keysight.com/find/3000X-Series-manual or on the Documentation
CD.
Dual-Channel
(N2820A Probe)
Measurements
Note that additional measurements are available with the N2820A high-sensitivity
current probe when both the Primary and Secondary probe cables are used.
Zoom In waveform data below the probe's clamp level is joined with Zoom Out
waveform data above the probe's clamp level to create the waveform on which the
measurement is made. These measurements are only valid for analog input
channels.
"X at Max Y" on page 232 Yes The resultant units are in Hertz.
"X at Min Y" on page 232 Yes The resultant units are in Hertz.
*
Use the cursors to make other measurements on FFT.
Measurement Valid
for
Math
FFT
*
Valid for
Digital
Channels
Notes
Dual-Channel (N2820A Probe)
Measurement
Notes
Amplitude See "Amplitude" on page 219.
Charge Charge (in Amp-hours) is the measured area under
the waveform. See "Area" on page 234.
Average See "Average" on page 222.
Base See "Base" on page 220.
Peak-Peak See "Peak-Peak" on page 219.
DC RMS See "DC RMS" on page 223.
AC RMS See "AC RMS" on page 223.
