Fuses
Refer to the following table for a description of the fuse.
Fuse Name Fuse rating Circuit Protected
MULTI FUSE-1
IG2 30A
Engine Room Junction Block (Start Relay), PCB Block
(Ignition switch2 Relay)
BLOWER 40A Engine Room Junction Block (Blower Relay)
ABS1 40A ESC (Electronic Stability Control) Module
B+2 50A
ICU Junction Block (Instrument Panel Module1, Instru
-
ment Panel Module3, Instrument Panel Module4, Fuse
- AMP (Amplifier), IBU (Integrated Body Control
Unit)1)
B+3 50A
ICU Junction Block (Instrument Panel Module5, Instru
-
ment Panel Module6, Instrument Panel Module7,
Instrument Panel Module8, Instrument Panel Mod
-
ule9, Instrument Panel Module10, Instrument Panel
Module11)
B+1 50A
ICU Junction Block (Fuse - P/SEAT(Driver), P/
SEAT(PASS), CHILD LOCK, MODULE1,
S/HEATER(RR), SAFETY P/WINDOW(Left Handle side),
SAFETY P/WINDOW(Right Handle side)
COOLING FAN 80A Cooling Fan Motor
MDPS 80A MDPS (Motor Driven Power Steering) Unit
MULTI FUSE-2
CVVD1 30A [Smartstream G 1.6 T-GDi] CVVD Actuator
E-CVVT1 40A
[Smartstream G 2.5 T-GDi] Engine Room Junction
Block (E-CVVT Relay)
IG1 40A PCB Block (Ignition switch1 Relay, ACC Relay)
REAR HEATED 50A Engine Room Junction Block (Rear Heated Relay)
EPB 60A ESC (Electronic Stability Control) Module
B+5 60A
PCB Block (Engine Control Relay, Fuse - Air Condition
-
er1, WIPER1, TCU (Transmission Control Unit)1, HORN,
ECU (Engine Control Unit)2)
OIL PUMP1 60A [Smartstream G 1.6 T-GDi] Electronic Oil Pump
OIL PUMP 60A [Smartstream G 2.5 T-GDi] Electronic Oil Pump
To Next Page
