Kia K5 2021 User Manual

57
7
7
Maintenance Fuses
FUSE
POWER OUT -
LET1
40A PCB Block (Power Outlet Relay)
W/S HEATED
GLASS RH
40A W/S Heated Glass Right Handle side Relay
W/S HEATED
GLASS LH
40A W/S Heated Glass Left Handle side Relay
TCU5 60A
[Smartstream G 2.5 T-GDi] TCM (Transmission Con -
trol Module)
B+4 60A
ICU Junction Block (Long Term Load Latch Relay, Fuse
- MODULE3, AIR BAG2, SUNROOF1, SUNROOF2,
S/HEATER (FRT), TRUNK, BRAKE SWITCH, DOOR
LOCK)
ECU5 10A
[Smartstream G 1.6 T-GDi] ECM (Engine Control Mod -
ule)
AMS 10A Battery Sensor
VACUUM
PUMP1
20A [Smartstream G 2.5 T-GDi] Vacuum Relay
4WD 20A
[Smartstream G 1.6 T-GDi] Audio/Video 4WD (4
Wheel Drive) ECU (Engine Control Unit)
FUEL PUMP1 20A Engine Room Junction Block (Fuel Pump Relay)
VACUUM
PUMP2
10A
[Smartstream G 2.5 T-GDi] ESC (Electronic Stability
Control) Module
E-CVVT3 20A
[Smartstream G 2.5 T-GDi] ECM (Engine Control Mod -
ule)
HEATED MIR -
ROR
10A Air Conditioner Switch
E-CVVT4 20A
[Smartstream G 2.5 T-GDi] ECM (Engine Control Mod -
ule)
Fuse Name Fuse rating Circuit Protected
