Configuration and Programming
P/N 06-237058-001 3-1 February 2012
CHAPTER 3
CONFIGURATION AND PROGRAMMING
3-1 INTRODUCTION
This chapter provides instructions on how to initialize an installed ARIES NETLink
TM
system, set up
password protection and program all configurable options in the menu system to make the system
ready for Normal Operation.
The ARIES NETLink system uses field-programmable software. An overview of the system menus
(accessible from the Keypad/Display) and instructions on how to program the ARIES NETLink are
provided in this chapter.
Refer to the ARIES NETLink Configuration Tool User’s Guide, P/N 06-237059-001, for instructions
on how to program the ARIES NETLink system from a PC or laptop. Refer also to the Operating
Instructions, P/N 06-237049-001, that are packaged with the ARIES NETLink system.
3-1.1 Initial Signaling-Line Circuit Configuration
Note: The following procedure assumes that all SmartOne devices have been addressed with the
Handheld Programmer or via the ARIES NETLink keypad. Refer to the instructions provided
with the Handheld Programmer to address SmartOne devices using this programmer.
Note: On the ARIES NETLink keypad, the BACKSPACE key () is located directly above the ENTER
key (
). In these instructions, the ENTER key is represented by its symbol:
Use this procedure to initially configure and check the number of SmartOne devices connected to the
SLC.
1. Connect the SLC wires to the applicable SLC Terminal Block. Refer to Figure 2-22 and
Figure 2-23 for typical SLC wiring.
2. Power the control unit, and set the time and date, by using the menu as depicted in this chapter.
3. All of the SmartOne devices connected to the SLC will report a not-registered trouble message
similar to the message shown in Figure 3-1:
Figure 3-1. Typical Device Not Registered Message
4. Wait for all of the device-not-registered troubles to report. Press the <ACKNOWLEDGE> Key one
or more times to silence the control unit buzzer.
5. Confirm that no more trouble messages have been reported.
6. Record the number of currently-active troubles. The number of troubles should be equal to the
number of SmartOne devices connected to the SLC.
7. Run the AutoLearn Routine as follows:
L3:025 NOT REGISTERED ON UNKNOWN TYPE
DISCHARGE-00 CNTDN-00 ABT-00 ALM-00
PREALM-00 AV CNTDN-00 SPV-000 TBL-001
Trouble Not-Registered Indication
Device Type Not Known
at This Time
Device
Address
Number
025
Panel Status
SLC Loop
Number 3
