Kidde Fire Systems ARIES NETLink User Manual

Installation
February 2012 2-20 P/N 06-237058-001
2-6 MAKING INTERNAL COMMUNICATION CONNECTIONS
Figure 2-16 provides an overview of internal communication connections for the ARIES NETLink
system.
Figure 2-16. Internal Communication Connections
-V 12-
Card Cage Backplane Additional Card Cage Backplane
PMU Board
Main Controller Board
Additional
PMU Board
To next Backplane or for Termination Plug
J10 J11
J10 J11
J12 J13
J12 J13
RS232 Ports
J9
J2
J12
To next Backplane or for Termination Plug
USB Ports
