Networking
P/N 06-237058-001 5-15 February 2012
Figure 5-11. Typical Remote Supervisory Message Display
The following actions also occur when the control unit is configured as Group 0 or when the
supervisory event is either from another control unit in the same group as the control unit or from
any other control unit in a network configured for global operation.
1. The Supervisory LED on the display flashes
2. The internal buzzer pulses
3. The supervisory event is stored in the event log
4. The supervisory message is transmitted to peripheral devices such as RDCMs, LAMs, and
ATM-Ls, if applicable
5. The supervisory message is communicated via the NIC and RS-232 ports, as applicable
6. Point- or group-specific and general-supervisory outputs activate, including previously-
silenced outputs.
Refer to Section 4-10.4 for what to do when a remote supervisory message is received.
5-8.12 Remote Pre-Alarm Events
Remote pre-alarm events from a networked control unit are shown in the upper line of the
LCD display by:
• Node-of-origin
• Device address
• Change of state
• Device type
The lower line indicates the up-to-40-character message assigned to the alarm-initiating device using
the ARIES NETLink configuration program.
Figure 5-12. Typical Remote Pre-Alarm Message Display
N:02 L1:070 SUPERVISORY ON MONITOR MODULE
FIFTH-FLOOR GATE VALVE
Supervisory On
Indication
Device Type
Node Number
Device Address L1:070
Device-Specific
Custom Message
N:03 L1:200 PREALM ON PHOTOELECTRIC
GROUND-FLOOR CONTROL ROOM
Pre-Alarm-On
Indication
Device Type
Node Number
Device Address L1:200
Device-Specific
Custom Message
To Next Page
